Ringlock Scaffold Diagonal Overview
our products
Ringlock Scaffold Diagonal Brace is an essential diagonal reinforcing member for ringlock scaffolding systems. Its cast steel wedge ends lock into ring discs of uprights, forming stable triangular structures together with uprights and ledgers. It effectively resists lateral loads and reduces frame deflection to enhance overall rigidity. Widely used for facade scaffolding, high formwork support, bridge & tunnel temporary supports, maintenance platforms and temporary grandstands.
Core Product Advantages
4 Core Product Advantages
Integrated Cast Steel Ends for Stable Load Performance
Our diagonal braces adopt one-piece precision cast steel ends, far superior to ordinary stamping ends with better crack resistance. Robotic full-circle welding eliminates poor welding and separation risks. Manufactured in accordance with EN12810 & EN12811, the braces effectively boost anti-sway and wind resistance, suitable for high-rise buildings and heavy-duty formwork projects.
Multiple Anti-Corrosion Treatments for High Reusability
Hot-dip galvanized and electro-galvanized options are available. Hot-dip galvanization fully covers tubes and welding seams to resist moisture, rain and acid corrosion, ideal for long-term cyclic use by scaffolding rental companies. Electro-galvanized solutions control costs for short-term projects and cut repeated procurement expenditure.
Standardized Modular Design and Wide Compatibility
Designed for universal 500mm modular ringlock discs, we supply a full range of standard lengths. Quick wedge lock installation enables fast assembly and disassembly without extra tools. Fully compatible with mainstream global ringlock scaffolding systems for easy matching with existing inventory.
Strict QC and Complete Certifications for Export All Ringlock Scaffold Diagonal Brace
undergoes full-process inspection from raw material to finished goods. Products are approved with CE and ISO9001 certification. We maintain sufficient inventory, support custom length and OEM service. Complete ringlock accessory packages and standard export packaging are provided for global bulk orders.
Product Name
Ringlock Scaffold Diagonal Brace
Material
Q235B high strength steel
Tube Spec
Φ48.3×3.0mm / Φ48.3×3.2mm
End Type
Integral cast steel end
Standard Sizes
0.73×2.0m, 0.88×2.0m, 1.09×2.0m, 1.40×2.0m (Custom sizes acceptable)
Surface Treatment
Hot-dip Galvanized / Electro Galvanized
Standards
EN12810, EN12811
Matching System
48 series ringlock scaffolding
Application Scenarios
Suitable for high-rise residential buildings, commercial complex facade scaffolding, bridge and tunnel high formwork, industrial plants, prefabricated construction, temporary stages and maintenance platforms. Perfect for scaffolding rental stock and meets construction standards in Europe, Southeast Asia, Middle East and Australia.
FAQ
faq
Q:1.What is Ringlock Scaffold Diagonal Brace used for?
A:It acts as diagonal bracing for ringlock scaffolding systems. Connected between uprights, it forms triangular stable structures, improves frame rigidity and prevents lateral displacement, widely used on facade scaffolding and formwork support.
Q:2.Do your diagonal braces comply with European standards?
A:Yes. All diagonal braces follow EN12810 and EN12811 standards and hold valid CE & ISO9001 certificates, acceptable for international project bidding and site inspection.
Q:3.What is the advantage of cast steel ends over stamping ends?
A:Integrated cast steel ends have higher density and impact resistance. They are not easy to crack under repeated loading, delivering longer service life and higher construction safety.
Q:4.Can I order customized lengths of diagonal braces?
A:Absolutely. Apart from standard sizes in stock, we support custom length, wall thickness and OEM marking to satisfy special project requirements.
Q:5.Are your diagonal braces compatible with global ringlock systems?
A:100% compatible. Our design matches international 500mm modular ringlock standard, which can freely cooperate with mainstream ringlock scaffolding accessories worldwide.
Q:6.Which galvanized finish is recommended for rental business?
A:Hot-dip galvanized diagonal braces are strongly recommended for rental companies. Excellent full anti-rust coverage supports repeated use for many years and lowers replacement costs.
One-stop Scaffolding Accessories Manufacturer Based in China
Shaanxi Flourish Industrial Co., Ltd. offers one-stop scaffolding service for global clients, including free sample testing, non-standard size customization and professional technical guidance. Factory direct sales avoid middleman markup with favorable bulk discounts. We supply full sets of ringlock scaffolding components and complete certification documents to support long-term cooperative procurement.
