Magnetic Pin Picker for Formwork

Magnetic Pin Picker for Formwork - The Safe & Efficient Cleaning Expert for Formwork Construction

It completely abandons the inefficient mode of "bending to pick up + broom magnet", with "15,000GS strong magnetic core + patented magnetic switch" as the core, achieving the triple breakthrough of "efficient adsorption, safe unloading, and easy operation". The cleaning efficiency of formwork accessories is increased by 80%, and the risk of injury from metal debris on construction sites is reduced to zero, making it an essential tool for retrieving pins and wires in aluminum and steel formwork construction.

1.1 Strong Magnetic Adsorption: Captures Tiny Accessories Completely​

Equipped with a neodymium-iron-boron rare earth magnetic core with a magnetic strength of 15,000GS, 5 times stronger than ordinary models, the adsorption distance extends to 8cm, which can instantly adsorb 0.5mm-diameter thin wires and 1g micro pins . The 35mm narrow magnetic head can reach narrow spaces such as formwork joints and steel bar gaps. With a 120° wide-angle adsorption surface, it can adsorb 10-15 pins at a time, avoiding repeated operations. Tested on concrete floor surfaces, the cleaning efficiency is 80% higher than traditional tools, saving an average of 2 hours per day on a single construction site.​

1.2 Patented Magnetic Switch: Safe Unloading Without Hand Injury​

Equipped with a patented push-pull magnetic shielding system, just pull the handle 25mm, the magnetic head retracts into the shield, and the adsorbed metal parts automatically fall into the collection bucket. No need to manually peel off sharp accessories, completely eliminating the risk of hand scratches and blood-borne disease transmission . When not in use, twist the handle to lock the "off" position, preventing the tool from adsorbing ironware or scratching equipment surfaces in the toolbox, improving storage safety.​

1.3 Ergonomic Design: Comfortable for Long-Term Use & Wide Adaptability​

Adopting an 80-135cm three-stage telescopic handle, it adapts to different working heights such as ground and high altitude (e.g., suspended slab soffit formwork). Operators do not need to bend over or climb, reducing the risk of waist strain by 90% . The handle is covered with non-slip TPR rubber with honeycomb patterns, ensuring a firm grip in wet conditions. The total weight is only 480g, which can be operated with one hand without soreness even after 4 hours of continuous work, suitable for long-term construction site operations.​

1.4 Durable Structure: Adaptable to Harsh Construction Environments​

The main body is made of 304 stainless steel rod with electrophoretic anti-rust treatment, achieving 5,000 hours of salt spray resistance without rust in humid concrete environments . The magnetic head is covered with an epoxy resin protective shell, which can withstand 1.5m drops without damage, and the magnetic attenuation rate is less than 5% per year (stable magnetism for more than 5 years under normal use). With IP65 waterproof rating, it can be directly rinsed with water to remove concrete residues, easy to maintain.

3.1 Core Magnetic Component (Key to Adsorption & Unloading)​

Composed of NdFeB magnetic core, stainless steel shield, and push-pull transmission rod. The magnetic core adopts a 7-layer stacking design to ensure uniform magnetic coverage. The shield is made of low-carbon steel, controlling the magnetic circuit through mechanical structure - when pushed, the magnetic circuit is open to adsorb metal parts; when pulled, the magnetic core retracts into the shield, and the magnetism disappears to realize unloading, with a transmission efficiency of 100% .​

3.2 Telescopic Main Rod (Core of Adaptability)​

Adopting a three-stage stainless steel sleeve, the length is adjusted through spring latches with a positioning accuracy of 1cm. The rod body adopts a hollow design to reduce weight while ensuring strength (can withstand 50kg axial pressure). With a hanging hole at the bottom, it can be hung for storage when not in use, saving tool storage space.​

3.3 Ergonomic Handle (Core of Operating Experience)​

The 12cm handle is designed to fit Asian hand shapes, providing a full grip. The 3mm thick non-slip rubber layer has shock absorption effect, which can buffer the reaction force during operation. The end of the handle is equipped with a lanyard hole, matched with the included wear-resistant nylon lanyard, preventing the tool from falling during high-altitude operations and improving construction safety.

Choosing Shaanxi Flourish's Magnetic Pin Picker for Formwork is a triple guarantee for construction efficiency, work safety and cost control. From narrow gaps to high-altitude operations, from aluminum formwork to steel formwork scenarios, we empower every formwork construction link with professional design!
