Shaanxi Flourish Industrial Co., Ltd.'s Frame Scaffolding System, backed by 20 years of low-rise construction expertise, redefines efficiency for small contractors and maintenance teams. Unlike over-engineered Kwikstage/cuplock systems built for skyscrapers, our door-frame design is precision-engineered for 1-6 story projects-delivering 30% lighter weight, 2x faster assembly, and 40% lower lifecycle costs. Crafted with high-tensile Q235 steel and 70μm hot-dip galvanizing, it meets EN 12811-1 safety standards while simplifying operations: 3 color-coded components, tool-free setup, and 200+ reuses.
Core Advantages (Built for Low-Rise Efficiency)
1. Foldable Door-Frame Rapid Assembly
Differentiator: Designed to eliminate coupler-type complexity and heavy-duty system redundancy:
Foldable Structure: Integral door-frame modules (1.2m×1.8m standard size) fold flat for transport-50 sets fit in a 5m truck (3x more than Kwikstage) .
Tool-Free Locking: Spring-loaded latch connectors secure crossbars in 15 seconds per set-no wrenches or bolts (2x faster than tube-and-coupler systems) .
Color-Coded Components: Frames (blue), crossbars (yellow), braces (red) reduce sorting time by 80%-beginners master assembly in 1 hour .
Real-world test: A 2-person team erected 40m² of 3-story scaffolding in 2 hours (vs. 6 hours for coupler-type) .
2. Low-Rise Optimized Safety & Compliance
Differentiator: Tailored safety features for 1-6 story scenarios, no over-engineering:
Load Capacity: 20kN/m² (supports 2 workers + tools, exceeding EN 12811-1's 15kN/m² minimum) .
Integrated Bracing: Pre-calibrated diagonal braces (45° angle fixed) meet DB11/945-2012 full-facade bracing requirements for low-rise structures .
Anti-Slip Protection: Perforated steel platforms (1.2m×0.6m) with 3mm raised treads-OSHA-compliant for wet conditions .
Stability Enhancements: Adjustable base jacks (0-300mm range) and ground pads (200mm×200mm×50mm) distribute weight to avoid foundation damage (critical for residential areas) .
3. Lightweight Durability & Reusability
Differentiator: Balancing portability with long-term performance:
High-Tensile Q235 Steel: 30% lighter than Q355 (12kg per standard frame) while maintaining yield strength of 235MPa .
70μm Hot-Dip Galvanizing: 1600-hour salt-spray resistance (ASTM B117 test) -resists dampness in basements and coastal regions .
200+ Reuse Cycles: Reinforced welds at frame corners (5mm weld bead) withstand repeated assembly/disassembly-3x longer lifespan than rental scaffolding .
Lifecycle cost comparison: 18/m² vs. 30/m² for rental systems (40% savings over 5 years) .
4. Space-Saving Storage & Transport
Differentiator: Solving small contractors' logistics pain points:
Fold-Flat Design: Frames fold to 15cm thickness-100 sets store in 2m³ (fits a standard garage) .
Modular Compatibility: Extendable crossbars (0.9m-1.5m) adapt to irregular wall shapes (e.g., bay windows) without custom parts .
Low Transport Cost: 1 ton of our system covers 80m²-0.5/m² transport cost vs. 1.2/m² for cuplock .
Product Specifications (vs. Traditional Systems)
|
Parameter |
Frame Scaffolding System |
Tube-and-Coupler Scaffolding |
Kwikstage Scaffolding |
|
Applicable Height |
1-6 stories (max 18m) |
1-20 stories (max 60m) |
6-30 stories (max 90m) |
|
Assembly Speed |
15s/set (tool-free) |
40s/node (wrench required) |
10s/node (semi-tool-free) |
|
Component Count |
3 core types |
8+ types |
5+ types |
|
Weight per m² |
35kg |
55kg |
70kg |
|
Load Capacity |
20kN/m² |
25kN/m² |
35kN/m² |
|
Corrosion Resistance |
1600h salt-spray |
1500h salt-spray |
1800h salt-spray |
|
Reuse Cycles |
200+ times |
150+ times |
250+ times |
|
5-Year Cost per m² |
$18 |
$28 |
$45 |
Core Components & Technical Details
1. Foldable Door Frames (Structural Backbone)
Spec: 1.2m (width) × 1.8m/2.0m (height), 48.3mm OD tubes, 2.75mm thickness .
Material: Q235 high-tensile steel (elongation ≥21%, impact toughness ≥27J) .
Feature: Foldable hinges (180° rotation) with powder-coated finish; integrated latch receivers .
Weight: 12kg per frame (30% lighter than Kwikstage standards) .
2. Spring-Loaded Crossbars (Horizontal Connection)
Spec: 0.9m/1.2m/1.5m lengths, 42.4mm OD tubes, 2.5mm thickness .
Material: Q235 steel with zinc-plated finish .
Feature: Dual spring latches (auto-lock when inserted into frame receivers); weight capacity 8kN per bar .
Installation: Align with frame holes → push until latch clicks (15 seconds per bar) .
3. Pre-Calibrated Diagonal Braces
Spec: 1.5m/1.8m lengths, 33.5mm OD tubes, 2.2mm thickness .
Material: Galvanized Q235 steel .
Feature: Fixed 45° angle; quick-connect pins fit frame lugs (no measuring required) .
Compliance: Meets DB11/945-2012 full-facade bracing requirements for ≤18m structures .
4. Safety Accessories
Non-Slip Platforms: 1.2m×0.6m galvanized steel (perforated surface, 2kN/m² load) .
Adjustable Base Jacks: 350mm-650mm height range, 50kN load capacity .
Guardrails: 1.2m height, tool-free clamp-on design .
Installation & Maintenance Guide
1. Step-by-Step Installation (2-Person Team)
Site Prep: Level ground → place base jacks (max 300mm height, spacing 1.5m×1.8m) .
Frame Placement: Unfold door frames → insert into base jacks (ensure verticality with spirit level) .
Crossbar Connection: Align yellow crossbars with frame receivers → push until latches click (15s/bar) .
Brace Installation: Attach red diagonal braces to frame lugs (45° angle, no adjustment needed) .
Safety Add-Ons: Lay non-slip platforms → clamp on guardrails (1.2m height) .
Pro Tip: For 4+ story structures, add horizontal braces every 2 layers (meets EN 12811-1 stability requirements) .
2. Maintenance & Storage (Prolong Lifespan)
Daily Check: Inspect latch functionality (ensure no debris blockage) and platform stability .
Weekly Maintenance: Wipe down galvanized surfaces with dry cloth (prevent moisture buildup) .
Post-Project Care: Disassemble → fold frames → store in dry area (avoid direct sunlight/rain) .
Repair Guide: Replace bent tubes (spare parts available within 48 hours) or worn latches (DIY replacement kit included) .
FAQ (Small Contractor Focus)
1. Why not use Kwikstage for low-rise projects?
Kwikstage is overengineered for 1-6 stories: it's 70% heavier (harder to transport), requires trained operators, and costs 2.5x more upfront. Our system skips redundant high-rise features (e.g., 35kN load capacity) to deliver what low-rise needs: speed, portability, and affordability .
2. Does it meet local safety standards?
Yes-certified to EN 12811-1 (EU), AS/NZS 1576.1 (Oceania), and OSHA 1926.451 (USA). It includes full-facade bracing (per DB11/945-2012) and anti-slip platforms to pass inspections first time .
3. How much storage space do I need?
50 sets (covers 50m²) fold to 1.5m³-about the size of a small refrigerator. Perfect for contractors with limited warehouse space .
4. What's the MOQ and delivery time?
MOQ is 10 sets (covers 10m²) for small projects. Standard orders ship in 3-5 days; custom sizes (e.g., 1.5m height frames) take 7-10 days. We offer free assembly training via video call .
Choose Shaanxi Flourish's Frame Scaffolding System-lightweight, fast, and built for small contractors-turn low-rise projects into profitable ones with every use!
